Instruction of the roll forming machine production line

This purlin roll forming machine is widely used in many kinds of industrial factory, workshop, civilian buildingsand so on , It has advantage of pretty appearance, durable using lower cost,high efficiency,reliable working and so on. - it has the standalone feeding table, the width is fixed by screw as customer's drawing. We can manufacture, design, installation and debug various roll forming machines including standard and customized machines.

The components that each set machine includes:

Hydraulic uncoiler------------------------------------------------------------------------1 set;

Guide platform----------------------------------------------------------------------------1 set;

Roll forming station----------------------------------------------------------------------1 set;

Hydraulic cutting device-----------------------------------------------------------------1 set;

Drive motor--------------------------------------------------------------------------------1 set;

Encoder-------------------------------------------------------------------------------------1 set;

Hydraulic pump station-------------------------------------------------------------------1 set;

PLC control system------------------------------------------------------------------------1 set;

Electronic components--------------------------------------------------------------------1 set.

Equipment Detailed Parameters:

Raw material
material spec	sheet, galvanized steel sheet, aluminum sheet
thickness of coil sheet	0.8-2 mm
Machine details
roller material	High grade NO. 45 forged steel with 0.05mm hard chrome plating
shaft material	High grade NO. 45 carbon wrought steel
cutting blade	Cr12 mould steel with quenched treatment
diameter of shaft	90 mm
forming steps	12 rows
productivity	8-12 m/min
hydraulic station power	11 KW
hydraulic pressure	10-12MPa
controlling system	famous PLC computer control
material of cutting table	Cr 12 mould steel with quenched treatment
appearance size	7500mm*1000mm*1500mm
hydraulic oil	40# hydraulic oil
Electric tension	380V 50 Hz 3 Phase or as your requirements

Our Machine Advantage

1. Good quality: We have a professional designer and experienced engineer team.And

the raw material and accessories we use are good.

2. Good service: we provide the technical support for whole life of our machines.

3. Guarantee period: within 2 year since the date of finishing commissioning. The guarantee covers all the electric, mechanic and hydraulic parts in the line except for the easy-worn parts.

4. Easy operation:All machine cotrolling by PLC computer controlling systerm.

5. Elegant apperance:Protect the machine from rust and the painted colour can be customized

6. Reasonable price:We offer the best price in our industry.

Guarantee:

12 Months guarantee. if some part of the machine is broken. we will supply the best part,but if the damaged parts due to operate error,buyer will pay for the shipping fee.

After-sale service:

We sent technician to your country to fix the machine.the buyer shoule bear all the cost includng:visa,roundtrip ticket and suitable accommodation,also buyer should pay the salary 100USD/DAY.

Q:Are you manufacturer?
A:Yes,we are manufacturer.We have our own technical team.Welcome to visit us.
Q:What kind o f payment term you can do?
A:We are flexible about payment terms,we can also help you on financing,please contact us for details.
Q:What info you need before you make the proposal?
A:The pipe diameter and thickness range which you need or the profile drawings,material information,your special requirements.
Q: What should I do if I just start a new business?
A:Contact us immediately ,we provide free consultant pre-sales service.Also we can help you to solve the material(steel coil)purchase,worker train,international market price.
